Manufacturer No:

SS14FL

Manufacturer:

ON Semiconductor

Package:

SOD-123F

Description:

Schottky Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 550mV @ 1A -55°C~125°C 30?A @ 40V 2-Termination Tape & Reel (TR) SOD-123F Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SS14FL information

ON Semiconductor SS14FL technical specifications, attributes, parameters and parts with similar specifications to ON Semiconductor SS14FL.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 2 days ago)
  • Factory Lead Time
  • 15 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • SOD-123F
  • Weight
  • 27.6mg
  • Diode Element Material
  • SILICON
  • Packaging
  • Tape & Reel (TR)
  • Series
  • Automotive, AEC-Q101
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin (Sn)
  • Max Operating Temperature
  • 125°C
  • Min Operating Temperature
  • -55°C
  • HTS Code
  • 8541.10.00.80
  • Capacitance
  • 60pF
  • Terminal Position
  • DUAL
  • Terminal Form
  • FLAT
  • Peak Reflow Temperature (Cel)
  • 260
  • Reach Compliance Code
  • not_compliant
  • JESD-30 Code
  • R-PDSO-F2
  • Number of Elements
  • 1
  • Element Configuration
  • Single
  • Speed
  • Fast Recovery =< 500ns, > 200mA (Io)
  • Diode Type
  • Schottky
  • Current - Reverse Leakage @ Vr
  • 30?A @ 40V
  • Voltage - Forward (Vf) (Max) @ If
  • 550mV @ 1A
  • Forward Current
  • 1A
  • Operating Temperature - Junction
  • -55°C~125°C
  • Output Current-Max
  • 1A
  • Max Reverse Voltage (DC)
  • 40V
  • Average Rectified Current
  • 1A
  • Reverse Recovery Time
  • 5.695 ns
  • Peak Reverse Current
  • 30?A
  • Max Repetitive Reverse Voltage (Vrrm)
  • 40V
  • Reverse Voltage
  • 40V
  • Max Forward Surge Current (Ifsm)
  • 40A
  • Max Junction Temperature (Tj)
  • 125°C
  • Height
  • 1.08mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ON Semiconductor SS14FL.

Datasheets:

PCN Design/Specification:

PCN Packaging:

ReachStatement:

SS14FL Description


The SS14FL is a Surface Mount Schottky Barrier Rectifier.



SS14FL Features


  • Ultra Thin Profile ? Maximum Height of 1.08 mm

  • UL Flammability 94V?0 Classification

  • MSL 1

  • Green Mold Compound

  • These Devices are Pb?Free, Halogen Free Free and RoHS Compliant



SS14FL Applications


  • Industrial

  • Automotive
