Manufacturer No:

NMLU1210TWG

Manufacturer:

ON Semiconductor

Package:

8-UDFN Exposed Pad

Description:

Single Phase Bridge Rectifier Schottky Surface Mount -55°C~125°C TJ 40?A @ 20V 450mV @ 2A 6-Termination 8-UDFN Exposed Pad Tape & Reel (TR)

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :100

Price not displayed? Please send an RFQ, and we will respond immediately.

NMLU1210TWG information

ON Semiconductor NMLU1210TWG technical specifications, attributes, parameters and parts with similar specifications to ON Semiconductor NMLU1210TWG.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 1 day ago)
  • Factory Lead Time
  • 11 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 8-UDFN Exposed Pad
  • Surface Mount
  • YES
  • Number of Pins
  • 8
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • -55°C~125°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2011
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 6
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin (Sn)
  • Technology
  • Schottky
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Pin Count
  • 8
  • JESD-30 Code
  • S-XDSO-N6
  • Number of Elements
  • 2
  • Diode Type
  • Single Phase
  • Current - Reverse Leakage @ Vr
  • 40?A @ 20V
  • Operating Mode
  • ENHANCEMENT MODE
  • Power Dissipation
  • 1.2W
  • Voltage - Forward (Vf) (Max) @ If
  • 450mV @ 2A
  • Case Connection
  • DRAIN
  • Transistor Application
  • SWITCHING
  • Current - Average Rectified (Io)
  • 3.2A
  • Polarity/Channel Type
  • N-CHANNEL
  • Continuous Drain Current (ID)
  • 2.2A
  • Peak Reverse Current
  • 1mA
  • Gate to Source Voltage (Vgs)
  • 10V
  • Drain Current-Max (Abs) (ID)
  • 1.16A
  • Drain to Source Breakdown Voltage
  • 20V
  • Drain to Source Resistance
  • 17mOhm
  • Height
  • 500?m
  • Length
  • 4mm
  • Width
  • 4mm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ON Semiconductor NMLU1210TWG.
