Manufacturer No:

MURB1620CTT4G

Manufacturer:

ON Semiconductor

Package:

TO-263-3, D2Pak (2 Leads + Tab), TO-263AB

Description:

Standard Rectifier Diode 1 Pair Common Cathode Fast Recovery =< 500ns, > 200mA (Io) -65°C~175°C 8A 200V-DC 2-Element TO-263-3, D2Pak (2 Leads + Tab), TO-263AB Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :100

Price not displayed? Please send an RFQ, and we will respond immediately.

MURB1620CTT4G information

ON Semiconductor MURB1620CTT4G technical specifications, attributes, parameters and parts with similar specifications to ON Semiconductor MURB1620CTT4G.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 4 days ago)
  • Factory Lead Time
  • 4 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
  • Surface Mount
  • YES
  • Number of Pins
  • 3
  • Diode Element Material
  • SILICON
  • Packaging
  • Tape & Reel (TR)
  • Series
  • SWITCHMODE?
  • Published
  • 2006
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin (Sn)
  • Max Operating Temperature
  • 175°C
  • Min Operating Temperature
  • -65°C
  • Additional Feature
  • FREE WHEELING DIODE
  • HTS Code
  • 8541.10.00.80
  • Subcategory
  • Rectifier Diodes
  • Voltage - Rated DC
  • 200V
  • Terminal Position
  • SINGLE
  • Peak Reflow Temperature (Cel)
  • 260
  • Current Rating
  • 16A
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • Base Part Number
  • MURB1620CT
  • Pin Count
  • 3
  • JESD-30 Code
  • R-PSSO-G2
  • Number of Elements
  • 2
  • Power Dissipation-Max
  • 3W
  • Element Configuration
  • Common Cathode
  • Speed
  • Fast Recovery =< 500ns, > 200mA (Io)
  • Diode Type
  • Standard
  • Current - Reverse Leakage @ Vr
  • 5?A @ 200V
  • Voltage - Forward (Vf) (Max) @ If
  • 975mV @ 8A
  • Forward Current
  • 8A
  • Operating Temperature - Junction
  • -65°C~175°C
  • Max Surge Current
  • 100A
  • Output Current-Max
  • 8A
  • Application
  • ULTRA FAST RECOVERY POWER
  • Halogen Free
  • Halogen Free
  • Forward Voltage
  • 975mV
  • Max Reverse Voltage (DC)
  • 200V
  • Average Rectified Current
  • 8A
  • Number of Phases
  • 1

Download datasheets and manufacturer documentation for ON Semiconductor MURB1620CTT4G.

Datasheets:

Environmental Information:

PCN Design/Specification:

PCN Assembly/Origin:

RohsStatement:

MURB1620CTT4G Overview


Devices that have a forward voltage of 975mV will operate.The maximum output voltage is 8A.Keeping the surge current under 100A and preventing it from exceeding it should be the rule.Devices that have a forward voltage of 8A will operate.Array is possible to draw current from the part of 16A.The reverse voltage peak of this device is 5?A.

MURB1620CTT4G Features


975mV forward voltage
a maximum output voltage of 8A
a peak voltage of 5?A
a reverse voltage peak of 5?A


MURB1620CTT4G Applications


There are a lot of ON Semiconductor
MURB1620CTT4G applications of rectifier diode array.


  • Rectifier for drives applications
  • Crowbar applications
  • Rectifiers for UBS
  • Battery chargers
  • Rectifiers in switch mode power supplies (SMPS)
  • Free wheeling diode in low voltage converters
  • General Rectification
