MMBF5484 information

ON Semiconductor MMBF5484 technical specifications, attributes, parameters and parts with similar specifications to ON Semiconductor MMBF5484.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 3 days ago)
  • Factory Lead Time
  • 16 Weeks
  • Contact Plating
  • Tin
  • Mount
  • Surface Mount
  • Package / Case
  • TO-236-3, SC-59, SOT-23-3
  • Number of Pins
  • 3
  • Weight
  • 30mg
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2008
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Max Operating Temperature
  • 150°C
  • Min Operating Temperature
  • -55°C
  • HTS Code
  • 8541.21.00.95
  • Subcategory
  • Other Transistors
  • Voltage - Rated DC
  • 25V
  • Max Power Dissipation
  • 225mW
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Current Rating
  • 10mA
  • Base Part Number
  • MBF5484
  • Number of Elements
  • 1
  • Element Configuration
  • Single
  • Operating Mode
  • DEPLETION MODE
  • Power Dissipation
  • 225mW
  • Output Power
  • 225mW
  • Transistor Application
  • AMPLIFIER
  • Breakdown Voltage
  • -25V
  • Transistor Type
  • N-Channel JFET
  • Continuous Drain Current (ID)
  • 5mA
  • Gate to Source Voltage (Vgs)
  • -25V
  • FET Technology
  • JUNCTION
  • Noise Figure
  • 4dB
  • Voltage - Test
  • 15V
  • Feedback Cap-Max (Crss)
  • 1 pF
  • Min Breakdown Voltage
  • 25V
  • Height
  • 930?m
  • Length
  • 2.92mm
  • Width
  • 1.3mm
  • REACH SVHC
  • No SVHC
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ON Semiconductor MMBF5484.

Datasheets:

Environmental Information:

PCN Obsolescence/ EOL:

PCN Design/Specification:

PCN Assembly/Origin:

PCN Packaging:

MMBF5484 Description

The MMBF5484 is a N-channel RF JFET Amplifier primarily designed electronic switching applications such as low ON-resistance analogue switching. Gate-Source Breakdown Voltage is -25?. ?Continuous Drain Current is 5 mA. The Maximum Drain Gate Voltage is 25v. And it can be operated from -55 to 150?.
