Manufacturer No:

FSB52006S

Manufacturer:

ON Semiconductor

Package:

23-PowerSMD Module, Gull Wing

Description:

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FSB52006S information

ON Semiconductor FSB52006S technical specifications, attributes, parameters and parts with similar specifications to ON Semiconductor FSB52006S.

  • Type
  • Parameter
  • Lifecycle Status
  • LIFETIME (Last Updated: 1 day ago)
  • Factory Lead Time
  • 6 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 23-PowerSMD Module, Gull Wing
  • Number of Pins
  • 23
  • Weight
  • 4.05g
  • Series
  • Motion SPM® 5
  • Published
  • 2011
  • Pbfree Code
  • yes
  • Part Status
  • Last Time Buy
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 23
  • ECCN Code
  • EAR99
  • Type
  • MOSFET
  • Max Operating Temperature
  • 150°C
  • Min Operating Temperature
  • -20°C
  • HTS Code
  • 8541.29.00.95
  • Subcategory
  • Motion Control Electronics
  • Max Power Dissipation
  • 11W
  • Terminal Position
  • DUAL
  • Number of Functions
  • 1
  • Supply Voltage
  • 15V
  • Voltage - Isolation
  • 1500Vrms
  • Power Supplies
  • 15V
  • Supply Voltage-Min (Vsup)
  • 13.5V
  • Configuration
  • 3 Phase
  • Max Current Rating
  • 2.6A
  • Output Current-Max
  • 5A
  • Supply Current-Max (Isup)
  • 0.16mA
  • Collector Emitter Voltage (VCEO)
  • 60V
  • Max Collector Current
  • 2.6A
  • Min Breakdown Voltage
  • 60V
  • Height
  • 3.15mm
  • Length
  • 29mm
  • Width
  • 12mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ON Semiconductor FSB52006S.

Datasheets:

PCN Design/Specification:

PCN Assembly/Origin:

PCN Packaging:

Description:
The ON Semiconductor FSB52006S is a Smart Power Module (SPM) designed for use in automotive applications. It is a high-efficiency, low-cost, and low-profile solution for driving power MOSFETs in automotive applications. The module is designed to provide a high level of integration and protection for automotive power systems.
