ON Semiconductor 74VCX16245GX

Manufacturer No:

74VCX16245GX

Manufacturer:

ON Semiconductor

Package:

54-LFBGA

Description:

BOTTOM Transceiver, Non-Inverting 1.2V~3.6V 3-State Buffers 74VCX Series 74VCX16245 8 Bit per Element 24mA 24mA 54-LFBGA

Quantity:

Delivery:

Payment:

In Stock :100

Price not displayed? Please send an RFQ, and we will respond immediately.

74VCX16245GX information

ON Semiconductor 74VCX16245GX technical specifications, attributes, parameters and parts with similar specifications to ON Semiconductor 74VCX16245GX.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
54-LFBGA

Surface Mount
YES

Operating Temperature
-40Â°C~85Â°C TA

Packaging
Tape & Reel (TR)

Series
74VCX

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
54

Technology
CMOS

Voltage - Supply
1.2V~3.6V

Terminal Position
BOTTOM

Terminal Form
BALL

Number of Functions
2

Supply Voltage
1.5V

Reach Compliance Code
compliant

Base Part Number
74VCX16245

JESD-30 Code
R-PBGA-B54

Output Type
3-State

Number of Elements
2

Supply Voltage-Max (Vsup)
3.6V

Number of Ports
2

Family
ALVC/VCX/A

Current - Output High, Low
24mA 24mA

Output Polarity
TRUE

Number of Bits per Element
8

Height Seated (Max)
1.4mm

Width
5.5mm

Download datasheets and manufacturer documentation for ON Semiconductor 74VCX16245GX.

Datasheets:

onsemiconductor-74vcx16245mtd-datasheets-2280.pdf

74VCX16245GX Overview

54-LFBGA packages are used to implement buffer. It is packaged in the Tape & Reel (TR) external packaging type for this voltage buffer. This digital buffer is available in the Surface Mount mount. There are a variety of applications for Transceiver, Non-Inverting logic integrated circuits. The logic IC is powered by 1.2V~3.6V. An ambient temperature of -40Â°C~85Â°C TA is suitable for this logical driver. There is a 24mA 24mA output current in the high and low logic states. 3-State outputs are supported. Transceiver uses all 2 elements. This is a network transceiver from the 74VCX series. 54 terminations are present in this ethernet transceiver, each of which serves a different purpose. A supply voltage of 1.5V is required. In the ALVC/VCX/A family, the electric component belongs. 2 ports have been added to this bus transceiver. Each element is represented by 8 bits. 74VCX16245 has other related electronic components that you can search for.
